GYD122/102/082
Technical Specification
| model | GYD122 | GYD102 | GYD082 |
| Operating mass(kg) | 12000 | 10000 | 8000 |
| Static linear load(N/cm) | 282 | 235 | 238 |
| Vibration amplitude(mm) | 0.74/0.35 | 0.74/0.35 | 0.67/0.34 |
| Vibration frequency(Hz) | 40/50 | 40/50 | 40/50 |
| Centrifugal force(kN) | 150×2/95×2 | 100×2/75×2 | 90×2/67×2 |
| Travel speed(km/h) | 11 | 13 | 13 |
| Gradeability(%) | 40 | 40 | 40 |
| Turning radius(mm) | 7200 | 6000 | 6000 |
| Drum width(mm) | 2130 | 2130 | 1680 |
| Drum diameter(mm) | 1400 | 1050 | 1050 |
| Wheelbase(mm) | 3590 | 3300 | 3300 |
| Ground clearance(mm) | 480 | 325 | 325 |
| Diesel engine model | DONGFENG 6BTAA5.9 | DONGFEGN 4BTAA3.9 | DONGFENG 4BTAA3.9 |
| Diesel engine power(kW) | 110 | 82 | 82 |
| Overall dimensions(mm) | 4960×2240×3000 | 4350×2290×3000 | 4350×1850×3000 |
